Our transformer insulation support strips are manufactured using highly refined and purified insulating press-board to ensure excellent performance in electrical applications. The material is carefully processed to achieve uniform thickness and is free from pinholes, undispersed fiber bundles, and other microscopic defects. This meticulous production process guarantees consistent quality and reliable insulation properties for your transformer applications.

Video:

Main Features of Insulation Support Strips:

1. These insulation support strips offer stable electrical and chemical characteristics combined with high physical strength, ideal for demanding applications.

2. Maintain their structural integrity and insulation properties even under continuous operation, providing dependable performance in transformers

3. These insulation support strips deliver the perfect balance of electrical safety and mechanical durability.

4. An excellent choice for various electrical insulation applications where safety and longevity are paramount.

Insulation Support Strips are vital structural elements within transformers, engineered to secure windings, maintain precise oil duct clearances, and enhance thermal management. Their design is crucial to the transformer’s mechanical strength, cooling performance, and insulation integrity.

Applications and Functions of Insulation Support Strips:

★Oil-Immersed Transformers:

Winding Fixation: Work together with upper and lower positioning rings and columnar spacers to create a robust mechanical support system, preventing winding short circuits or deformation.

Cooling Optimization: The spacing between insulation support strips directly influences oil flow. Elongated hole designs (e.g., 20–30 mm spacing, 5–8 mm diameter holes) increase the heat dissipation surface area.

★Dry-Type Transformers:

Utilize high-temperature-resistant materials (e.g., Class F, 155°C) to avoid softening or deformation under thermal stress.

★Special Scenarios:

High-Humidity Environments: Employ anti-hygroscopic materials such as polyimide composites.

High-Frequency Transformers: Optimized dielectric properties help minimize partial discharge risks.

These insulation support strips can also be used to make Transformer Ladder Duct Struct
